2024 Honda FourTrax Foreman 4x4

CAPABILITY YOU CAN COUNT ON

For many enthusiasts, the Honda Foreman ATV can be considered the original “Do-it-yourself” expert. It has set the highest standards of performance, durability, and overall build quality for the entire category. And it’s all thanks to a capable 518cc engine that’s ready for hard work and hard trail riding. A swingarm rear suspension that’s ideal for towing. Long-travel suspension and a plush seat that provides a comfortable ride all day long. And steel front and rear racks are not just sturdy, but also designed to easily integrate with Honda Pro-Connect™ cargo boxes and other accessories. The Foreman is the ATV for those who never cut corners on the job, or miss a shortcut on the trail.

Important Safety Information: Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

• Engine Type
  518cc longitudinally mounted liquid-cooled single-cylinder four-stroke
• Bore And Stroke
  96.0mm x 71.5mm
• Compression Ratio
  9.5:1
• Valve Train
  OHV; two valves per cylinder
• Induction
  Programmed Fuel Injection (PGM-FI); 36mm throttle body
• Starter
  Electric with optional auxiliary recoil
• Clutch
  Automatic
• Transmission
  Five-speed with reverse
• Driveline
  Direct front and rear driveshafts with TraxLok® and front differential lock
• Front Suspension
  Independent double-wishbone; 7.3-inch travel
• Rear Suspension
  Swingarm with single shock; 7.3-inch travel
• Front Brakes
  Dual 190mm discs
• Rear Brakes
  160mm sealed mechanical drum
• Front Tires
  25 x 8-12
• Rear Tires
  25 x 10-12
• Length
  82.9 inches
• Width
  47.4 inches
• Height
  47.8 inches
• Wheelbase
  50.0 inches
• Seat Height
  34.5 inches
• Ground Clearance
  7.5 inches
• Curb Weight
  635 pounds (includes all standard equipment, required fluids and a full tank of fuel)
• Fuel Capacity
  3.9 gallons, including 1.3-gallon reserve
• Turning Radius
  10.5 feet
• Towing Capacity
  848 pounds
• Front Rack Capacity
  88 pounds
• Rear Rack Capacity
  176 pounds
